Punching Machine Manufacturer: Amada Type: Aries 245 Year of construction: 1989 CNC Control: Amada 04PA Operating hours: approx. 20,000 Punching force: 200 KN Sheet thickness (stainless steel) max.: 3 mm Sheet thickness (mild steel) max.: 4 mm Sheet thickness (aluminum) max.: 3 mm Travel: 1,270 x 1,000 mm Revolver: 20-fold (2x rotatable B-stations) Incl. complete set of tools ! Power: 11 KVA Dimensions: LxWxH = 2,700 x 3,784 x 1,950 mm Weight: 7,500 kg plus 2,500 kg foundation slab
We offer our reliable Amada Aries-222 punching machine for sale here. The machine is fully functional. The associated tool kit is complete and the machine is fully equipped.
Description: serial number: 179 control: FANUC Series 180i-PB working hours: approx. 17808 hrs.  , punching force: 300 kN travels: X-axis: 2500 mm Y-axis: 1525 mm max. material thickness: 4.5 mm max. table load: 160 kg positioning speed: X-axis: 100 m/min. Y-axis: 80 m/min. axis simultaneous: 128 m/min. number of turret stations: 45, of which rotatable: 4 max. tool diameter: 114.3 mm turret turning speed: 30 rpm overtravel: 360 mm number of punching strokes: max. number of punching strokes: 1000/min. with 25.4 mm hole spacing: 500/min. marking mode: 1800/min. connected load: 27 kVA  , please also have a look at the PDF document and the video of this machine  , fixed collection period: 24.06. - 28.06.2024 plate thickness: 4.5 mm, total power requirement: 27 kW, weight approx.: 24,500 kg, Approx. Onsite Dimension. (l x w x h): 5,120 x 4,900 x 2,310 mm
Description: Comes from an industrial company that had to restructure its production and currently has no work for this machine. , It has not been working for about a year, but in February 2024 it was put into operation and you can see the videos they made on this date.  ,It can be visited by appointment. Serial Number: 255 - 251 Max. capacity: 200 kn Nominal Curent: 40A Power: 400 v, 50hz Installed power: 20 kw Overall response time: 450 ms Minimun separation distance: 1,6 m Widthc guarded area: 30 m (maxi) Stopping time : 430 ms Stopping distance: 190 mm CNC: FANUC 18P 31 Turret Station Turret Rotation: 30 rpm Max sheet dimensions: 1270x1270 mm Max sheet thickness: 6 mm Feeds. Rapid feeds:  ,X+Y: 82 m/min Automatic loading: No Working hours 2187h (según contador) CE standard weight approx.: 9,500 kg, Approx. Onsite Dimension. (l x w x h): 5,030 x 2,630 x 2,160 mm
Description: Including reel , Machine number 21491weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 2,000 x 2,000 mm
Description: Including reel , Machine number 20175weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 2,000 x 2,000 mm
Description: Including reel Installation number 5001weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 2,000 x 2,000 mm
Description: Including reel ,weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 2,000 x 2,000 mm
Description: Serial number 3016 , Voltage 400 V, frequency 50 Hz , with BIHLER P CNC 400 control unit Including reelweight approx.: 4,000 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 2,000 x 2,000 mm
Description: Serial number 175-25-0062.9 24330 Including reel ,weight approx.: 6,000 kg, Approx. Onsite Dimension. (l x w x h): 6,000 x 2,400 x 2,400 mm
Description: sheet metal punching machine EDEL Stanzomat 410 - 20 with CNC technology serial number: 2811388 control: EF200S  , well preserved , possibility of manual and automatic operation (saved programs) include many tools, original instructions in German  , please also have a look at the PDF document of this machine weight approx.: 4,500 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 2,500 x 2,000 mm
Description: Maximum power 40 mp (400 kN), tool size up to 100 mm diameter, diameter 100 mm in 3.5 mm, rectangle 70 mm in 4 mm, including extensive accessoriesweight approx.: 3,500 kg, Approx. Onsite Dimension. (l x w x h): 6,000 x 3,000 x 2,000 mm
Punching machine EDEL - Maximum power: 25to. - Extension 26 cm - Height: 170cm - Width: 65cm - Depth: 50cm Good condition fully functional can be visited and tried out on site. Shipping abroad. Visit: Basically, I would like to point out to you that in order to avoid misunderstandings, the article can be viewed before purchase and tested under electricity. Please ask questions before purchasing to avoid any ambiguity. If you have any general questions or make an appointment for a visit, I can be reached at any time, using the telephone number below or above. Errors in the description and intermediate sale reserved. The VAT is shown separately on my invoices. Shipping with forwarding.
serial number: 28043 weight: 3 tpressure: 30 tvolt: 380 Vfrequency: 50 HzThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Inv. Num. : 6731 Type: CX 1000/30 Producer: EUROMAC Created: 1999 Parameters: Compressive force: 30 t Maximum lifting speed: 200 mm/s Feed length X-axis: 2000 mm Feed length Y-axis: 1000 mm Stroke: 60 mm Machine height: 1800 mm Machine length: 4000 mm Machine width: 2800 mm Machine weight: 5250 kg
Euromac punching and nibbling machine type: CX1250/30 with light barrier, multi-tool and individual tools with extensive tool. With tool cabinets. The machine is in top condition and can be viewed under power.
Technical data: -maximum cutting force 300 kN -maximum punching diameter up to 88.9 mm -Max that material thickness 6.35 mm -Work area without putting up 1000 x 2000 mm -Actual workspace 1145 x 2100 mm -Work area normally with putting 1000 x 4000 mm -Size work table 1000 x 3500 mm -maximum working speeds of the axes 50 m / min -Max stroke sequence. 320 strokes/min -2 collets min. / max. distance 160-1900 mm -Need for compressed air 6 bar -Power supply 400 V / 15 kW -Space B 4200 x T H 3800 x 2250 mm -Weight approx. 6500 kg -with:-tool station 360-degree rotatable programmable 0.01 ° -CNC control - div. accessories in the separate tool Cabinet
Punching machine X5 Manufacturer: FINNPOWER YEAR: 2006 Desktop... 2530x1270mm Nominal pressing force... 056 Axis X ... 2584mm Axis Y ... 1317mm thickness of the cut material ... 8mm Magazine slots ... 20 Control Fanuc ... Oi-PC Machine weight ... 10500kg L x W x H ... 7600x6980mm The machine is in good condition, possible to test under power.
Description: Punching power 80 t , Maximum capacity 40×14 mm , Throat S / SD 510 / 750 mm , Working height S / SD 1094 / 1194 mm , GENERAL SPECIFICATIONS , Motor power 9 kw , Strokes/minute with 20 mm Stroke 40 Maximum , Stroke 70 mmweight approx.: 1,400 kg, Approx. Onsite Dimension. (l x w x h): 4,200 x 1,600 x 3,000 mm
Description: Triple punch 80 tonne punching power Standard gooseneck (S) 500mm Additional gooseneck (SD) 750 Steel punching capacity 42 kg/mm2 mm Ø 40 x 14 Ø 24 x 24 Punching U and I flanges 100 - 300 mm Core punching U 120 - 380 mm Core punching I 100 - 500 mm Adjustable stroke for shearing and punching stations 0 to 70 mm Punching device Gd. Ø (Option) mm Ø 100 x 6 / 50 x 12 Includes : Punching machine. Automatic X & Y positioning table without clamps. Triple punching device 31 - 40 - 31. Fitted with a Fagor 102 S control. Servomotor mobility group, independent for each axis, controlled by encoderweight approx.: 2,100 kg, Approx. Onsite Dimension. (l x w x h): 2,500 x 1,300 x 2,150 mm
plate length: 300 mm, weight approx.: 85 kg, Approx. Onsite Dimension. (l x w x h): 620 x 320 x 800 mm
Description: serial number: 504 control: ASEM power: 18 kW pressure: 10 bar X-axis travel (with repositioning, processing up to 4,000 mm): 2500 mm travel along the 1st axis: 1250 mm max. sheet thickness: 6mm max. stamping diameter: 105 mm tool clamping: hydraulic clamping of the workpiece: clamping head max. stroke length: 7-70 mm impact speed: 200 impacts/min single / continuous stroke: yes drive: 5 kW tank capacity / hydraulics: 100 l including accessories weight approx.: 9,000 kg, Approx. Onsite Dimension. (l x w x h): 3,250 x 4,800 x 2,100 mm
Serial No.: 1704 Punching capacity: Ø 28 x 16 Available with special tools: Ø 100 x 4 Year of construction: 1997 Country of origin: Italy
Punching capacity: 25 tplate thickness: 10 mmno. of strokes: 120 Hub/minpunch diameter: 105 mmpositioning accuracy: 0,1 mmweight of the machine ca.: 1.800 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Indumasch IS 25-500 - Punching machine - Holder for Trumpf punching tools - Digital position display for X and Y axis - incl. tools & accessories - Year of construction 1993 Specification - Capacity: 25 t - Max. sheet thickness: 6 mm - Max. stamp thickness: 90 mm - Stroke rate: 200 rpm - Projection: 510 mm - Motor power: 4 kW - Operating voltage: 400 V - Dimensions WxHxD: 1000 x 1770 x 1350 mm - Weight: approx. 2000 kg
Description: 30 tonnes of power 4KW 610MM gooseneck Rate 35 strokes / minuteweight approx.: 12,000 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 900 x 1,700 mm
- Working pressure: min 6 - max. 7 bar - Machine weight: 170 kg - Space requirement (W x D x H): 0.55 x 0.55 x 1.4 m - Condition: very good Details for profile WICONA, system WICLINE 50E - 50EN, 60E, CODE:332.04.10 from vocational school, was hardly in use, as good as new
Description: SPECIFICATIONS Character: Peddinghaus Type: 210 Super 11 Machine dimensions (L×W×H): 1,500 x 1,000 x 1,800 mm Capacity: 40 T Round: 34 mm ø Square: 30 mm ø Strip: 120 x 12 mm Angle iron: 100 x 10 mmweight approx.: 1,100 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 1,000 x 1,800 mm
Description: SPECIFICATIONS Brand: Peddinghaus Type: 210 Super 13 Machine dimensions: (L×W×H) 1800 x 1000 x 2100 mm Capacity: 65 T incl. various punches weight approx.: 5,000 kg, Approx. Onsite Dimension. (l x w x h): 1,800 x 1,000 x 2,100 mm
Description: SPECIFICATIONS Character: Peddinghaus Type: 210 Super 20 Capacity: 95 T Punch: 30 x 25 mm Round: ø55 mm Square: ø50 Strip Angle iron Unloading: 500 mm Electrical installationweight approx.: 5,000 kg, Approx. Onsite Dimension. (l x w x h): 1,400 x 2,300 x 2,400 mm
• Machine number: 4221875989007 • Punching force max: 800kN • Material thickness max: 25 mm • Punching device max: Ø 90 mm • Accessories according to photos (sold separately on request)
Hydropneumatic functioning Punching power: 50 kN Height: 140 mm
The notching machine is in used condition and is fully functional. Ideal for the production of round or square air ducts. - Incl. substructure table with castors - Pneumat. Actuation via foot switch Condition see pictures. Visit and demonstration possible. The indicated price is a net price for collection ex works. A chargeable transport within Germany can be organized on request.
Description: SPECIFICATIONS Brand Sahinler Type: HPM 65 Year of construction: 2013 Capacity 65 T Punch capacity: ø26 in 20 mm Slag cylinder: 55 mm Unloading: 625 mm Working height: 950 mm Number of strokes: 22 p/min Power: 5.5 kW Table with material stop Hydraulic control Machine dimensions (L×W×H): 1,600 x 900 x 1,800 mm Machine weight: 2,440 kg weight approx.: 2,500 kg, Approx. Onsite Dimension. (l x w x h): 1,600 x 900 x 1,800 mm
Offer 22526 Specifications: - Pressure capacity at 10 bar 35 KN - Plunger stroke 12 mm - Projection 95 mm - Installation height approx. 134 mm - Table size approx. 230 x 190 mm - Air consumption per stroke 8.0 l - Air inlet 6 - 10 bar - Space requirement approx. W 520 x H 1450 x D 600 mm - Weight approx. 100 kg - with: - Foot switch - Pressure gauge + pressure regulator - 4 x punching tool
Offer 22523 Specifications: - Pressure capacity at 10 bar 35 KN - Plunger stroke 12 mm - Projection 95 mm - Installation height approx. 134 mm - Table size approx. 230 x 190 mm - Air consumption per stroke 8.0 l - Air inlet 6 - 10 bar - Space requirement approx. W 520 x H 1450 x D 600 mm - Weight approx. 100 kg - with: - Foot switch - Pressure gauge + pressure regulator - 4 x punching tool
5018 – PNEUMATIC PRESS, PUNCHING, FERRULE DEVICE Manafacture: Sepalumic Model No.: ZA00069 SH0011B Dimensions: 900 x 350 x 1 100 mm Operating pressure: 6 bar
Description: PUNCHING Punching force: 60 ton Punching capacity: Ø22 x 20 mm (Diameter x Thickness): Ø40 x 11 mm Throat depth: 200 mm Maximum stroke length: 40 mm Cycles / Min. (15 mm stroke): 34 mm Working height up to mould: 1050 mm  , ANGULAR CUTTING Cutting force: 60 ton With 90° cut: 100 x 100 x 8 mm Working height: 1070 mm  , FLAT SHEAR Flat bar shear: 350 x 15 mm Blade length: 360 mm Working height: 805 mm  , BAR SHEAR Shear for round bars: ø40 mm Shear for square bars: 38 x 38 mm Cutting channels: 102 mm optional tool I-beam cutting: 102 mm optional tool NOTCHING Rectangular notching (W x D x T): 50.8 x 90 x 8 mm V-cut (L x W x T): 90 x 90 x 8 mm optional tool Working height: 1050 mm  , SPECIAL TOOLS optional  , Single Vee press brake (W x T): 160 x 8 mm tool optional Multi Vee press brake (W x T): 250 x 6 mm tool optional Angle bending: 65 x 8 mm optional ...
Description: PUNCHING Punching force: 55 ton Punching capacity: Ø22 x 18 mm (diameter x thickness): Ø50 x 8 mm  , Punching channel flange (height): 180 mm Throat depth: 510 mm Maximum stroke length: 100 mm Cycles/Min. (20 mm stroke): 28 Table dimensions (W x D): 700 x 700 mm Working height up to mould: 1050 mm  , OPTIONAL TOOLS. Largest bore: Ø160 x 3 mm optional tooling Single V-bending press (W x T): 250 x 15 mm optional tooling Multiple V-bending press (W x T): 500 x 5 mm optional tooling Angle bender: 102 x 9 mm optional tool Rectangular notching machine (W x D x T): 63.5 x 90 x 8 mm optional tool V-shaped notching machine (L x W x T): 145 x 145 x 6 mm optional tool Pipe notching machine (maximum diameter): Ø 100 mm optional tool Flat bar shearing: 175 x 7 mm optional tool Corner shearing: 100 x 100 x 7 mm optional tool Blanking of round bars: Ø 32 mm optional tool Squar ...
Description: pressure: 30 tons max punch stroke: 20 m/min. floor movement: 750 x 3000 mm max. range copying: 800 x 1500 mm important: oil pipe is leaking  , please also have a look at the PDF document of this machine weight approx.: 3,300 kg, Approx. Onsite Dimension. (l x w x h): 2,400 x 2,700 x 2,100 mm
Description: Serial Number: A15.564 CNC : TRUMPF Main Drive , Punching Force : 180 KN Max. sheet thickness: 6.4 mm Strokes: ,  ,X-AXIS: 1250 mm  ,Y-AXIS: 1280 mm Max. workpiece thickness , Steel: 4 MM Max. workpiece weight: 75 kg , Max. workpiece height: 38 mm , Programmable force: 4000-17000kn Speeds: , X-axis: 90 m/min Y-axis: 60 m/min Simultaneous: 108 m/min Power: 400 V / 50 HZ Installed power: 17 KVA Important note: , The machine is currently stored as shown in pictures 5-12.  ,max. punching diameter: 76 mm, weight approx.: 9,200 kg, Approx. Onsite Dimension. (l x w x h): 5,530 x 2,300 x 2,255 mm
Standard configuration? Stable C-frame? Coordinate guide with integrated linear magazine, 11 tool stations for tools and clamps? Drives: Maintenance-free, digital three-phase servo motors? Punching head: Hydraulic system with closed control loop, single tool adapter, 360? rotation of all tools? Automatic repositioning device with programmable presser foot ? Vacuum slug removal? Swarf bucket? Brush tables? Parts chute 200 x 200 mm and sorting of parts into 2 containers? 2 parts containers? Controller BOSCH Type 3, activity-oriented user interface, Online help,diagnostic functions, 3.5 disk drive, BNC/RJ45 connection, TFT color screen 10.4? Graphic programming ToPs 2000? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdownAdditional equipment? MultitShear? MultiBend? SoftPunch? Table extension? Start post
Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 87500 hours (03.2021) In this case, the configuration : TruMatic TC3000-1300 FMC Year of construction 2004 Working range : 2550 x 1280 mm Standard: • Sturdy C-frame • Coordinate guidance with integrated linear magazine, 21 seats for tools and clamps • 2 clamps • Drives: Maintenance-free digital three-phase servo motors • Punching head: hydraulic system with closed control loop, hydraulic mono tool holder, 360° rotation for all Tools, automatic tool length compensation, programmable scraper movement • Programmable hold-down • Tool spray lubrication • Punch butt suction • Partial slide 500 x 500 mm • Control Bosch PNC-P, activity-oriented user interface, Online Help, Diagnostics, 3.5" Floppy Drive, RJ45 Network Connection • Graphics programming ToPs 2000 • ToP ...
Manufacturer / Manufacturer: Trumpf Typ / Type: Trumatic 500 Rotation Stocknummer / stock number: 1008 Year of Manufacture: 1995 Punching force: 22 tons Max. sheet thickness: 8 mm Connected load: 19 kVA Machine weight: 13,8 tons
Punching machine Trumpf TruMatic TC500-1300 FMC Year of construction 2000 Configuration : TruMatic TC500-1300 FMC Year of construction 2000 Working area : 2550 x 1280 mm The machine has the following options : • Function multi-tool control • Function thread forming • Winning function • Softpunch function • 1 additional Clamping claw • Sensor for parts chute • Vibration-damped installation • Automatic switch-off • Scratch arm machining for tables •Blow-out device for small parts •Trumasort L6 • Loading station with expansion magnets • TRL SheetMaster 1300 • TrumaGrip 200 mm with scissor lift table
Standard configuration? Stable C-frame? Coordinate guide with integrated linear magazine, 18 tool stations, automatic tool changer, 3 clamps? Automatic parts chute 500 x 500 mm? Parts container ? Drives: Maintenance-free, three-phase servo motors? Programmable presser foot for repositioning? Punching head: Hydraulic single tool adapter, 360? rotation of all tools, automatic tool length compensation, spray tool lubrication, 2nd lubricant container, programmable stripper movement, vacuum slug removal, swarf bucket? Control: 32 bit microprocessor control TRUMAGRAPH CC 220 S, 10.4 color screen, programmable logic controller, easy to use, diagnostic functions, graphic programming TRUMAGRAPH, integrated 3.5 disk drive, RJ45 network connection? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdownAdditional equipment? Function MultiTool? Pneumatic repositioning cylinders? Sens ...
Description: serial number: A0150A0078 operating hours: approx. 100607 hrs. working time of the resonator: approx. 99232 hrs.  , punching force: 220 kN max. sheet thickness: 8 mm max. workpiece weight: 280 kg working range: punching operation X-axis: 3050 mm punching operation Y-axis: 1550 mm laser operation X-axis: 3050 mm laser operation Y-axis: 1550 mm combined operation ,X-axis: 2500 mm combined operation Y-axis: 1550 mm max. stroke rate: punching: 1200 mm/min , marking: 3000 mm/min , number of tools / clamps: 21 pieces / 4 pieces laser-specific data: max. laser power: 4000 W max. sheet thickness mild steel: 8 mm max. sheet thickness stainless steel: 8 mm max. sheet thickness aluminum: 6 mm part ejection: max. part size part flap punching: 500 x 500 mm max. part size rigid chute punching (with sliding table): 80 x 50 mm max. part size laser part flap: 500 ...
Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 82500 Hours (03.2024) Here is the configration : TruMatic TC6000-1600 FMC Year of construction 2005 Working area: 2585 x 1650 mm Standard equipment: - Stable C-frame - Coordinate guidance with integrated linear magazine, 21 slots for tools and clamping claws. - 3 clamping claws - Drives: Maintenance-free three-phase servo motors - Programmable hold-down device for resetting - Sensor-monitored parts chute 500x500 mm for punching and laser station, ejection cylinder on laser chute - 2 boxes of good parts - Laser unit: High-frequency excited CO2 laser TLF 2000, vibration-isolated in the machine frame, incl. cooling unit and laser control DIAS 3 - HI-LAS high-pressure cutting - ContourLas for making small holes - Programmable cutting gas pressure setting - Laser cutting head: 5" lens, quic ...
Standard configurationMachine? Stable C-frame for easy access? Coordinate guide for high-precision machining? Linear magazine with 17 tool stations, 2 clamps? Drives with maintenance free 3-phase servo motors? Repositioning unit with programmable stripper? Ball tables? Parts chute 180 x 150 mm? Swarf bucket? Punching head? Hydraulic punching head? Rotatable single tool adapter? 360? rotation of all tools? Programmable presser foot? Tool length compensation? Spray lubrication for punches? Vacuum slug removal? FormingControl? Controller based on Bosch PNC-P? Control panel with 15 TFT color touch screen? Easy to use? Online-help? Integrated USB interface? RJ 45 network connection? Diagnostic functionsSafety? CE marking? Light barriers? Rapid hydraulic shutdownAdditional equipment? Function Multitool? Function MultiShear? Function Roller Technology? Adjustable support table? Sensor for parts ...
Standard configurationMachine? Stable C-frame for easy access? Coordinate guide for high-precision machining ? Linear magazine, 3 clamps? Maintenance free drives? Repositioning device with programmable presser foot? Parts chute 500 x 500 mm? Good parts container? Swarf bucketCutting head? Hydraulic punching head? Single tool adapter? 360? rotation of all tools? Programmable presser foot? Tool length compensation? Spray lubrication for punches? Vacuum slug removal ? FormingControl? Open control system based on BOSCH? Control panel with TFT colour screen 12.0? ? Program management? Online-help? Integrated technology data? Diagnostic functions? TeleserviceProgramming? Machine-oriented shopfloor programmingData transmission? Disc drive and network connectionSafety? CE marking? Light barriers? Rapid hydraulic shutdownAdditional equipment? Function Multitool? Function MultiShear? Function Tap ...
