turbines used for sale

Hydroelectric power station - Power 790 kW composed of: 1 Turbine Pelton / Effective gradient 223m / Water volume 400 l/s / 1 piece generator 1 shut-off device 1 hydraulic power unit 1 piece transformer

1015 KW Dresser counterpressure steam turbine for sale. 35.000 € plus VAT FCA freely charged in D-Bergisch Gladbach. TUBRINE Brand: DRESSER-RAND (Nadrowski) Type: AVT 72 TW 17 Number: 16225-1 Electr. Power: 1015 KW Rated power: 1375 kVA Year of construction: 1995 (control units upgraded in 2008) Voltage: 400 V RPM: 1500 rpm Steam flow rate: 25 tons /h Dimensions (l x w x h): 4.50 x 2.40 x 2.30 m Inlet temperature: 253°C Inlet pressure : 18 bar Exhaust temperature : 152°C Outlet pressure : 5.0 bar Steam flow rate at the entrance: 25 tons/h Turbine weight: 11,000 kg Generator Brand: Leroy Somer Type: NWR 50 BL10-4P Electrical power : 1015 KW SWITCHBOARD Manufactured by TIL SA and updated in 2008 Schneider control

Price on request. FCA free loaded in our warehouse. One second hand Siemens Twin AFA 46 condensing steam turbine manufactured in 2009 for sale. turbine: Siemens type: Twin AFA 46 el. power: 3.300 KW running hours: steam consuption: steam inlet pressure: 26 bar inlet steam temperature:400°C manufactured: 2009 generator: AVK powerrating: 4.125 KVA volts: 6.300 volts Hz: 50 Hz price on request: Stromerzeuger-Discount Kürtener Straße 13 D-51465 Bergisch Gladbach Mobile: 0049/1635263546 Telefon: 0049/ 2202 2492256 Fax: 0049 2202 2492257 Email: info@stromerzeuger-discount.de

1300 KW KK&K CFR3 G5A tandem condensing steam turbine 40 bar inlet pressure from 1997 with 50.000 running hours in very good working condition for sale. Scope of supply: controlpannel, turbine with generator, documents. turbine: KK&K type: CFR3 G5A el. power: 1300 KW steam inlet pressure: 40 bar manufactured: 1997 generator: AEM type: SE 500 M4 powerrating: 1830 KVA volts: 400 volts Hz: 50 Hz price on request: Stromerzeuger-Discount.com Kürtener Straße 13 D-51465 Bergisch Gladbach Mobile: 00491635263546 Telefon: 0049 2202 2492256 Fax: 0049 2202 2492257 Email: info@stromerzeuger-discount.de

Used turbine from german coal-fired power plant. This turbine was fully operational until the power plant was shut down acc. to governmental decision based on Energy Transition Program (change to green energy). This turbine is offered for disassembly by buyer. Further pictures and technical details on demand!

SIEMENS SGT800 gas only turbine Year: 2022. Brand new. OEM warranty 3 x 56MW, 60Hz No photos are available, units are still at the Siemens factory Only 3 units are available

Steam turbine Siemens SST400 Year: 2011 Disassembled and put in a storage. Very low working hours. Power:30mW Voltage:10.5kV/50Hz Fuel: Biomass Generator: SGen5-100A-4P Turbo gear unit Flender-Graffenstaden TX80/3 Transformer Siemens S10-40000/110 Condenser Full set of manual books No boilers, no voltage control cabinet (7) Steam turbine Siemens SST-400 Year: 2011 Never used and never installed. Still in original wooden crates. Packing lists. 7 sets available Power:30mW Voltage:10.5kV/50Hz Fuel: Biomass Generator: SGen5-100A-4P Control system Accessories Full set of manual books No boilers Price: on request

Kawasaki Model TD80A-1 7.2 MW Type TD80A Rated Output 7216 kW Voltage 11000 V Frequency 50 HZ Current 446 A Phase 3 Gas Turbine M7A-03D Generator NTAKL-DC YOM 2011 low hours 7836

750 MW each, UNUSED Gas Based Complete Combined Cycle Power Plants 2 units available Technical Specifications: The Project Details: 1. EACH module has two Gas turbines GE 9FA.03 (DLN2+) and one Steam turbine GE D11. Each GT exhaust is directed to the triple pressure unfired, natural circulation horizontal, type CMI USA HRSG. This configuration helps turndown operation of station up to 45%. 2. The Station is based on robust design of GE Gas Turbine with high efficiency DLN2+ Dry low Nox system, each GT is site rated for an output of 235 MW and the triple pressure reheat GE D11 Steam Turbine with downstream Exhaust, is site rated at 266 MW. The HRSG is a Triple pressure, Natural circulation, Horizontal design type with Deaerator atop the LP drum. Thus Net Combined cycle efficiency at Site condition is approx 57% on LHV basis. The inherent design of the gas turbine reduced the N ...

16 x 3.2MW 60Hz KAWASAKI Gas Turbine Power Plant Main specifications - Gas Turbine Model: M1T-23 x 16 sets - Maker: KAWASAKI - Power Output: 3,200kWe - Frequency & Voltage: 60Hz & 6600V - Year of Production: 2008 - Running Hours: about 60 hours - Fuel Oil: Natural Gas - Plant Auxiliary Equipment: 1 set This gas turbine plant has 16 x 3.3MW gas turbines with the optimal layout of 4 x 4 blocks and was initially installed as an emergency power supply in preparation for major disasters or large-scale power outages in the area. Fortunately, as there has been no serious emergency, this plant has had almost no operation, and the total running hours does not exceed 60 hours for each unit until today. However, as the plant has been regularly checked and well maintained, now the gas turbines units are in the best condition. This power plant is scheduled to be shut down i ...

5.5MW 60Hz KAWASAKI PUC60 ECOPLUS Gas Turbine Power Plant This is an eco-plus gas turbine power plant that has been being operated successfully for over 160,000 hours since it was manufactured in 2002 and installed. This plant has been regularly inspected and very well maintained according to the maintenance manual by the operating company. Now, the plant is scheduled to go for sale after stopping its commercial operation around June 2023. Main specification: - Gas Turbine Model: KAWASAKI PUC60 ECOPLUS - Maker: KAWASAKI - Power Output: 5,570kW - Frequency & Voltage: 60Hz & 3300V - Year of production: 2002 - Running Hours: 163,858 hours - Fuel Oil: Natural Gas - Plant Auxiliary Equipment: 1 set

215 MW Toshiba Inlet Steam Turbine & Generator (Unused and well maintained) New in 2008, this Power Plant has never been used and is available for immediate inspection and delivery. Never having been used, the Plant has no wear whatsoever. The Steam Turbine: Extraction & condensing, Inlet pressure: 104 bar, Output: 215MW Extractions: MP2: 22 bar, MPI: 10 bar, LP: 4.5 bar, Feed Water: 0.4 bar Minimum load: • No extractions, Only bleeds, Steam flow: 45 kg/s Maximum load: Steam flow: 270 kg/s The turbine is a Single Flow Extraction Condensing type. Steam initially enters the steam inlet flange near the end of the high pressure section and flows through the turbine stages toward the generator end of the unit. After passing through the turbine stages, the steam is exhausted to condenser. The exhaust hood is keyed to the foundation plates at a point near its ce ...

1. General specification -Maker MES (Mitsui Engineering & Shipbuilding Co., Ltd.) Japan -Mfg. data 2014 -Running time Zero hoursP 2. Steam turbine specification -Maker MES (Mitsui Engineering & Shipbuilding Co., Ltd.) Japan -Turbine type CD30.46 -Steam in let pressure 70barG -Steam inlet temperature 490℃ -No.1 Extraction steam P & T 31.5barG & 388.5℃ -No.2 Extraction steam P & T 5.5barG & 223.3℃ -Nor. Exhaust pressure 0.11barA -Turbine speed 3,600 rpm -Rated output 97,500 kw -Weight 132 ton -Number of stages 16 -Number of 1 stage nozzle arcs 4 -Steam inlet flange ASME1500#RJ12” x 2 -No.1 extraction steam flange ASME 600#RF 16” -No.2 extraction steam flange ASME 150#RF 32” -Steam exhaust flange ø3,600(inner dia.) 3. Synchronous generator -Standard IE60034-1(2010), IEC60034-3(2007) -Location Indoor -Cooling system Totally enclosed type with top-moun ...

Make and model: Turboden ORC Year: 2016 Electrical capacity: Ran at 700kW (Normal rating: 643 kW) V: 400 HZ: 50 Now available for sale . Price: 400,000 GBP

Turbogas Turbine GE5/1 5MW Natural gas for sale. Complete turbogas turbine plant with electric generator, recovery boiler and exchangers, dry cooler, diverter. Total Hours: 36,000 8,000 hours from the last overhaul. THERMAL POWER 9,0 MWt Saturated steam production 13,000 kg/h at 10BARg Voltage 11000 V Frequency 50 hZ Also available: - GE5/1 used turbine in nitrogen storage with 72,000 hours + 8,000 Hours after the last overhaul + one used generator. Price: €300,000 - NEW GE5 Turbine Spare Parts (value 1 million) Price: €400,000

3 MW Siemens Steam Turbine SST-110 TWIN AFA 46 K Year: 2010 Hours: 5,200 Capacity: 3,224 kW Volts: 400 HZ: 50 Condition: Very Good Scope of Supply: Complete Turbine Power Station Turbine and alternator Control Panel Condensor Cooling Towers Spilling Unit Switchgear Synchronisation panel Transformer Piping / wiring / pumps Boiler not included Inspected in Very Good Condition. Dismantled and loaded to your transport.

Condensing Steam Turbine Peter Brotherhood Ltd. (England) Power Output – 3500 kW Normal Running Speed – 7035 RPM Trip Speed – 7739/8090 RPM Steam Inlet Pressure – 40 bar G Steam Inlet Temperature – 480° C Exhaust Pressure - 0.10 bar A

TO WHOM AT MAY CONCERN ; WE VE NEW UNUSED 3 SETS NAPIER NA 307 GAS INLET& OUTLET CASINGS AND INLET ELBOWS AT OUR STOCK. 3 SETS GAS INLET & OUTLET CASINGS ARE NEW AND NEVER MONTAGED . PLS REFER SOME PICTURES ON ATTACHE IF YOU VE ANY QUESTIONS . PLS DO NOT HESITATE TO CONTACT WITH US . Capt. Ayhan Ugurluba With Kind Regards ; Aliaga Marine Services E mail: info/aliagamarine.com Phn/Fax:+90 232 618 03 90 Mobile: +905556084850 aliagamarine.com TURKEY

1 piece ABB TPL 77-B12 turbocharger complete available New In our stock in Istanbul Please contact: info@fin-marine

Complete 96 MWe gas fired black start/ peak load power station, consisting of 4 (four) GE Frame 5N Gas Turbine Sets 24 MW each. Each set consists of a: • Gasturbine • Generator • Diesel Engine • Main Gearbox • Auxiliary Gearbox • Speedtronic Mark II control system • Exhaust plenum • Air inlet filter house 125 MVA transformer With or without building. additional info on request.
